MQTT Series #2: Potential risks of exposed MQTT brokers

Jan 02, 2020

In our first post, we mentioned that there are over 47,000 exposed MQTT brokers that can be connected to authentication-free. Are these MQTT brokers vulnerable to cyber attack? We will cover the risks and their mitigation in this blog.

Using Shodan, a list of topics can be found for exposed MQTT brokers, as can be seen in our example below (though not all exposed brokers have a list of topics on Shodan).



This can be done by subscribing to a topic using the wildcard ‘#’. The MQTT client uses wildcards to subscribe to multiple topics simultaneously, and ‘#’ can be used to subscribe to multiple levels of topics simultaneously . A subscriber can use this to subscribe to multiple topics with a single subscription message. However, this feature could be abused if there is no limit on subscriptions. An attacker could obtain any MQTT messages across the entire server by subscribing with the wildcard ‘#’ . Therefore, it is important to restrict the use of wildcards, especially ‘#’, since it allows subscription to any topic and therefore access to a tremendous amount of potentially sensitive data.

It’s important to note that topics listed above without a ‘$’ symbol will be retained messages (These ‘$’- marked topics are reserved for the internal statistics of the MQTT broker). A retained message is a normal MQTT message with the retained flag set to ‘ true ’ . The broker stores the last retained message and the corresponding QoS for that topic, and only one retained message is saved per topic.
Each client that subscribes to a topic of the retained message receives the message immediately after he or she subscribes.

The retained message eliminates the wait for the publishing clients to send the next update.

This is a useful feature — however, it lets someone sniff your messages easily. In other words, an attacker can immediately get access to all your messages by subscribing with the wildcard ‘#’.
The below image describes the mechanism. In order to prevent this from happening, it’s recommended to limit the use of retained messages to situations when they’re strictly necessary.
While you may not think that the contents of MQTT messages being accessed is a serious problem, seeing which topics publishers or subscribers communicate on could be very useful to attackers!

Since the MQTT protocol is based on the principle of publishing messages and subscribing to topics, subscribers will not be able to know who is publishing a message. Subscribers only subscribe to topics that they are interested in. Therefore, if anyone can connect to a broker and publish a message to the existing topics, it’s easy to alter or overwrite the data.

The topic ‘garage/door/command’ was actually observed in Shodan data, so it’s easy to conduct this kind of attack and get into the garage if you get to know where it’s located. In order to prevent this kind of attack, it is important to set an Access Control List (ACL) for both publishers and subscribers.

Furthermore, in order to secure your MQTT brokers and messages, implement Transport Layer Security (TLS) when possible. However, many IoT devices have limited resources and may not be able to support TLS due to its significant overhead. In such a case, it would be good to implement payload encryption. Even if someone sniffs your MQTT messages and gets information on the topic, the payload will be protected. If someone tries to publish a message with a topic but not an encrypted payload, a subscriber would notice that it’s not the right message and someone is trying to overwrite the payload on the topic.

Lastly, Shodan has a “compromised” tag. Even though we are not sure how they define ‘compromised’ devices, it’s interesting to note this detail. Even though the volume is very small, some compromised MQTT brokers are tagged. We’ve checked these brokers, and found that ActiveMQ has more compromised brokers than Mosquitto. Since ActiveMQ is designed for enterprise use, we can conclude that enterprise brokers are likely to be more easily targeted.

The following is the map of compromised brokers.
This graph shows known vulnerabilities for Mosquitto and ActiveMQ. As you may notice, ActiveMQ has a lot more known vulnerabilities than Mosquitto, so it may be easily compromised if not patched regularly. Be aware that it’s necessary to keep patches up-to-date.
